Hot Line Clamp

About Our Hot Line Clamps

Pranami Metal is a renowned leader in the manufacturing of Hot Line Clamps, serving a diverse clientele spanning the globe.

Part no Connection Type Run Connection Type Tap Run Dia. Run Tap Dia. Tap
HLC 1 CU CU .128"-.414" #8 sol- 2/0 str .128"-.414" #8 sol- 2/0 str
HLC 2 CU CU .162"-.745" #6 sol- 400 MCM .152"-.682" #6 sol- 4/0 str
HLC 3 AL AL/CU .250"-.860" #4 ACSR- 477 MCM .250"-.860" #4 ACSR- 477 MCM
HLC 4 AL AL/CU .502"-1.031" 4/0 ACSR- 800 MCM .198"-.703" #4 sol- 350 MCM

Our Commitment to Quality

At Pranami Metal, we uphold unwavering standards to deliver Hot Line Clamps of the utmost quality. We prioritize the following key parameters to ensure excellence:

Premium Materials: Our Hot Line Clamps are meticulously crafted using corrosion-resistant aluminum and bronze alloy castings.

Enhanced Eye Bolts: To guarantee uniform expansion during loading and exceptional tensile strength, we employ forged stainless steel for our eye bolts.

Optimized Design: We have widened the jaw of our clamps to establish superior conductor contact, reduce twisting, and minimize joint temperatures, thus enhancing overall durability.

Metal Specifications

Each component of our Hot Line Clamps is constructed from carefully selected metals to meet rigorous specifications:

Hot Line Clamp Body: Crafted from robust bronze alloys, ensuring exceptional strength.

Eyebolts: For unparalleled durability, our eyebolts are forged from stainless steel.

Keepers and Eyelets: We employ aluminum bronze to create keepers and eyelets, ensuring both strength and corrosion resistance.

Clamp Finish: Choose from a variety of finishes, with natural and tin coating being the most common options.

Our Product Range

Explore our product offerings:

Hot Line Clamps

Earthing and Grounding Solutions

Lightning Protection Systems

Key Features

Our Hot Line Clamps are characterized by:

Unmatched Strength: Engineered for high-strength performance.

Corrosion Resistance: Exceptional resistance to corrosion ensures longevity.

Conductor Compatibility: Designed to accommodate various conductor types.

All-Weather Durability: Capable of withstanding even the harshest weather conditions.


Pranami Metal Hot Line Clamps find utility in a wide range of applications, including:

UHotline Tap Connections

Full Duty Connections

Mainline Joints

Bimetal Connections

Discover the premium quality and reliability of Pranami Metal Hot Line Clamps, engineered for excellence in every detail.
